CLASSIC BATTLE GREEN
- Over View
The Classic Battle Green comes to you with a paint scheme reminiscent of the War era, a time when Royal Enfield motorcycles proved their capabilitities and battle worthiness by impeccable service to soldiers. Donning a younger look with styling cues one would expect only from a genuine Royal Enfield: single cylinder air-cooled pushrod engine, 1950s style nacelle and toolboxes, traditional paint scheme and buffed engine components, this motorcycle is all set to bring you the pleasures of modern motorcycling while reflecting the aura of classic eternal styling.
- Displacement
499 CC
- Gearbox
5 Speed
- Fuel Capacity
14.5 Ltr
- TECHNICAL SPECIFICATIONS
| ENGINE | |
|---|---|
| Type: | Single Cylinder, 4 stroke |
| Displacement: | 499cc |
| Bore x stroke : | 84mm x 90mm |
| Compression Ratio: | 8.5:1 |
| Maximum Power: | 27.2 bhp @ 5250 rpm |
| Maximum Torque: | 41.3 Nm @ 4000 rpm |
| Ignition System: | Digital Electronic Ignition |
| Clutch: | Wet, multi-plate |
| Gearbox: | 5 Speed Constant Mesh |
| Lubrication: | Wet sump |
| Engine Oil: | 15 W 50 API, SL Grade JASO MA |
| Fuel Supply: | Keihin Electronic Fuel Injection |
| Air Cleaner: | Paper Element |
| Engine Start: | Electric & Kick |
| CHASSIS & SUSPENSION: | |
| Type: | Single downtube, using engine as stressed member |
| Front suspension: | Telescopic, 35mm forks, 130mm travel |
| Rear suspension: | Twin gas charged shock absorbers with 5-step adjustable preload, 80mm travel |
| DIMENSIONS: | |
| Wheelbase: | 1370mm |
| Ground Clearance: | 135mm |
| Length: | 2160mm |
| Width: | 800 mm |
| Height: | 1050mm |
| Kerb Weight: | 187 Kg (with 90% Fuel & Oil) |
| Fuel Capacity: | 14.5 Ltr (3.2Gallon) |
| BRAKES & TYRES: | |
| Tyres Fr.: | 90/90 - 19(Domestic), 90/90 - 18(Export) |
| Tyres Rr.: | 120/80 - 18(Domestic), 110/80 - 18(Export) |
| Brakes Front : | 280mm Disc, 2-Piston caliper |
| Brakes Rear: | 153mm Drum, Single Lead Internal Expanding |
| ELECTRICALS: | |
| Electrical System: | 12 volt - DC |
| Battery : | 12 volt, 14 Ah |
| Head Lamp: | 60 W / 55 W, HALOGEN |
| Tail Lamp: | 21 W / 5 W |
| Turn Signal Lamp: | - |
